ovCatch 300 Night Fishing Light

Target Users (Target Impact Group)

Distributors / Implementing Organizations

Purchase directly from Omnivoltaic Energy Solutions.

Manufacturing/Building Method

Mass produced in Guanzhou and Shenzhen in China.

Intellectural Property Type

Patent Protected

User Provision Model

Direct purchases from Omnivoltaic Energy Solutions.

Distributions to Date Status

Unknown

Design Specifications

Solar PV Module: 13W Polycrystalline Silicon. Battery: Lithium Ion 8800mAh, at 3.6V Description of Lighting Points: 12 LEDs Colour Characteristics: CRI 83 CCT "Daylight" (>5000 K) Waterproof: The lighting unit meets IP67

Technical Support

Available from the manufacturer.

Replacement Components

Available from the manufacturer during the two-year warranty period.

Lifecycle

5 Years

Manufacturer Specified Performance Parameters

Unknown

Vetted Performance Status

Lighting Global has vetted the following performance parameters: 1. Truth in Advertising 2. Lumen Maintenance 3. AC-DC Charger Safety 4. Battery Composition, Battery Protection, Battery Durability. 5. Physical Ingress Protection 6. Water Ingress Protection 7. Drop Test 8. Soldering and Electronics Workmanship 9. Mechanical Durability 10. Minimum Warranty Terms 11. Performance Reporting

Safety

Follow proper electrical installation and control guidelines.

Complementary Technical Systems

None

Academic Research and References

Compliance with regulations

The ovCatch 300 has complied with the Lighting Global Quality Standards, and has been tested according to the Quality Test Method stipulated in the IEC 62257 - 9 -5 Standard.

Other Information

None
